Thương hiệu: Schneider
Tình trạng: Còn hàng
Hỗ trợ vận chuyển tuỳ theo thoả thuận đơn hàng
Hỗ trợ thanh toán tiền mặt, thẻ visa tất cả các ngân hàng
Hỗ trợ chăm sóc khách hàng 24/7
Thiên Năng Tecch là thương hiệu được yêu thích và lựa chọn
| MAIN | |
| range | Masterpact |
| product name | MasterPact NT |
| product or component type | Switch disconnector |
| device short name | Masterpact NT10 |
| switch-disconnector name | Masterpact NT10HA |
| device application | Protection |
| poles description | 3P |
| network type | AC |
| network frequency | 50/60 Hz |
| [Ie] rated operational current | 1000 A AC 50/60 Hz 690 V |
| [Ui] rated insulation voltage | 1000 V AC 50/60 Hz conforming to IEC 60947-3 |
| [Uimp] rated impulse withstand voltage | 12 kV conforming to IEC 60947-3 |
| [Icm] rated short-circuit making capacity | 75 kA 220...690 V AC at 50/60 Hz |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz conforming to IEC 60947-3 |
| breaking capacity code | HA |
| suitability for isolation | Yes conforming to IEC 60947-3 |
| contact position indicator | Yes |
| visible break | No |
| pollution degree | 3 conforming to IEC 60664-1 |
| COMNPLEMENTARY | |
| control type | Push-button |
| mounting mode | Drawout |
| mounting support | Chassis |
| upside connection | Front |
| downside connection | Front |
| operating rate | 10 cyc/h maximum |
| [Icw] rated short-time withstand current | 20 kA during 3 s conforming to IEC 60947-3 36 kA during 0.5 s conforming to IEC 60947-3 36 kA during 1 s conforming to IEC 60947-3 |
| mechanical durability | 12500 cycles without maintenance conforming to IEC 60947-3 |
| electrical durability | AC-23A: 3000 cycles 690 V AC 50/60 Hz without maintenance conforming to IEC 60947-3 AC-23A: 6000 cycles 440 V AC 50/60 Hz without maintenance conforming to IEC 60947-3 AC-3: 6000 cycles 440 V AC 50/60 Hz without maintenance conforming to IEC 60947-3 |
| connection pitch | 70 mm |
| height | 301 mm |
| width | 276 mm |
| depth | 196 mm |
| net weight | 14 kg |
| ENVIROMENT | |
| standards | IEC 60947-3 |
| product certifications | LCIE ASEFA |
| ambient air temperature for operation | -5…70 °C |
| ambient air temperature for storage | -40…85 °C |
| Offer Sustainability | |
| Sustainable offer status | Green Premium product |
| REACh Regulation | REACh Declaration |
| EU RoHS Directive | Compliant EU RoHS Declaration |
| Mercury free | Yes |
| RoHS exemption information | Yes |
| China RoHS Regulation | China RoHS declaration Product out of China RoHS scope. Substance declaration for your information |
| Environmental Disclosure | Product Environmental Profile |
| Circularity Profile | End of Life Information |
| PVC free | Yes |
| Contractual warranty | |
| Warranty | 18 months |
