Flange immersion heaters - HEATING LIQUIDS - Viet Nam

HEATING GASES - HEATING LIQUIDS - MAINTAINING A CONTINUOUS
Tube materials
• Stainless steel
- AISI 321 (1.4541)
- AISI 316L (1.4404)
- AISI 309 (1.4828)
• Others
- Incoloy 800 (1.4876)
- Incoloy 825 (2.4858)
- Inconel 600 (2.4816)
- Titanium
• Specific coating
- TeflonTM (PTFE)
- Halar
Tube diameter
• 6.5 / 8.5 / 10 / 13.5 / 16 mm
Flange
• All diameters (including very large sizes)
• NF EN 1092-1 (European standard, PN)
• NF EN 1759-1 (European standard,Class)
• ASME B16-5 (American standard)
• Others standards on request
• Material choice according to application and
standards (carbon steel, stainless steel or
others)
Mounting
• Vertical or horizontal position
Electrical
• Voltage: VAC or VCC
• Cabling according to main voltage VAC/VCC
1PH + N or 3PH
• Power : a few Watt to several Megawatts
Connecting box (non-ATEX)
• IP 54 / IP 66 / IP 67
• Material: painted steel, stainless steel,
aluminium
• Polyamide or nickel-plated brass cable gland
ATEX/IECEx connecting box
• Explosion-proof connecting box, aluminium,
stainless steel or painted steel, Ex d IIC
• Stainless steel increased security enclosure,
Ex e IIC
• Nickel-plated brass cable gland
(stainless steel as option)
Standard documentation
• Certificate of conformity to the order
• Heater wiring diagram
• Instruction manual
On-request documentation
• Supplied according to directives, standard
and construction code
• Welder qualifications (QS)
• Welding qualifications (QMOS)
• DESP documentation
• Material certificate 3.1 acc. to NF EN 10204
Certifications (if requested)
• According to standard to comply with
• ATEX/IECEx certificate for component or
system
• EAC CU TR, c CSA us (NEC500)
